Angular Signals and NgRx Signal Store: A Dialog State Management Feature
August 21st, 2025 | 5 min read
Last update: August 29th, 2025
In the last post, I showed a pretty basic example (you can find the previous post here). Let's step this up a bit :)
As always, if you want to see the complete code checkout the github repository:
NGRX Signal Store Feature
I haven't shown you the best part of the ngrx/signals package yet, and that is the signalStoreFeature function, arguably one of my favorite things about this library.
It basically allows you to create a feature that can be used in however many stores you want, you can even compose multiple features together to create a more complex store.
Let's reuse the matcha counter example from the previous post and turn it into a feature:
// With features it's better to use interfaces to define the state
interface MatchaState {
cups: number;
brewing: boolean;
}
// Create the initial state
const initialMatchaState: MatchaState = {
cups: 0,
brewing: false,
};
// Create the matcha store feature
export const withMatchaFeature = () =>
signalStoreFeature(
withState(initialMatchaState),
withMethods((store) => ({
brewMatcha() {
if (!store.brewing()) {
patchState(store, { brewing: true });
setTimeout(() => {
patchState(store, {
cups: store.cups() + 1,
brewing: false,
});
}, 2000);
}
},
drinkMatcha() {
if (store.cups() > 0) {
patchState(store, { cups: store.cups() - 1 });
}
},
resetMatcha() {
patchState(store, initialMatchaState);
},
}))
);
export const MatchaStore = signalStore({ providedIn: 'root' }, withMatchaFeature());Pretty simple! The usage of the store is the same as before, but now we can plug this into any store we want.
The Dialog Signal Store Feature
I want to have the following capabilities in our dialog store:
- Open and close dialogs
- Set loading state
- Set results and errors
- Prevent closing based on custom conditions (like form dirty state)
- Provide metadata for the dialog
First, we define the types we need for the dialog feature.
export const DialogStatus = {
Closed: 'closed',
Open: 'open',
Loading: 'loading',
Error: 'error',
Completed: 'completed'
} as const;
export type DialogStatus = (typeof DialogStatus)[keyof typeof DialogStatus];
export interface DialogState<TConfig, TResult = unknown> {
isOpen: boolean;
loading: boolean;
config: TConfig | undefined;
result: TResult | undefined;
error: unknown;
metadata: Record<string, unknown> | undefined;
preventClose: boolean;
}
export interface DialogOpenOptions<TConfig> {
config: TConfig;
metadata?: Record<string, unknown>;
preventClose?: boolean;
}
export interface ClosePreventionOptions {
isDirty?: boolean;
hasUnsavedChanges?: boolean;
isProcessing?: boolean;
customCondition?: boolean;
}These are pretty self-explanatory. I want to have as much flexibility as possible to avoid unforeseen issues in the future.
Now we can implement the dialog store feature using the signalStoreFeature function:
import { computed } from '@angular/core';
import { patchState, signalStoreFeature, withComputed, withMethods, withState } from '@ngrx/signals';
export function withDialogFeature<TConfig, TResult = unknown>(config?: TConfig) {
const initialState: DialogState<TConfig, TResult> = {
isOpen: false,
loading: false,
config: config,
result: undefined,
error: undefined,
metadata: undefined,
preventClose: false,
};
return signalStoreFeature(
withState(initialState),
withComputed((store) => ({
canClose: computed(() => !store.loading() && !store.preventClose()),
hasError: computed(() => !!store.error()),
hasResult: computed(() => store.result() !== undefined),
dialogStatus: computed((): DialogStatus => {
if (store.loading()) return DialogStatus.Loading;
if (store.error()) return DialogStatus.Error;
if (store.result() !== undefined) return DialogStatus.Completed;
if (store.isOpen()) return DialogStatus.Open;
return DialogStatus.Closed;
}),
isInFinalState: computed(() => {
const hasError = !!store.error();
const hasResult = store.result() !== undefined;
return hasError || hasResult;
}),
})),
withMethods((store) => ({
setLoading(isLoading: boolean) {
patchState(store, { loading: isLoading });
},
toggleLoading() {
patchState(store, { loading: !store.loading() });
},
setResult(result: TResult) {
patchState(store, { result });
},
setError(error: unknown) {
patchState(store, { error, loading: false });
},
clearError() {
patchState(store, { error: undefined });
},
setMetadata(metadata: Record<string, unknown>) {
patchState(store, { metadata });
},
setPreventClose(prevent: boolean) {
patchState(store, { preventClose: prevent });
},
setFormDirty(isDirty: boolean) {
patchState(store, { preventClose: isDirty });
},
configureClosePrevention(options: ClosePreventionOptions) {
const shouldPrevent = !!(options.isDirty || options.hasUnsavedChanges || options.isProcessing || options.customCondition);
patchState(store, { preventClose: shouldPrevent });
},
clearPreventClose() {
patchState(store, { preventClose: false });
},
open(config?: TConfig, metadata?: Record<string, unknown>) {
patchState(store, {
isOpen: true,
loading: false,
config,
result: undefined,
error: undefined,
metadata,
preventClose: false,
});
},
openWithOptions(options: DialogOpenOptions<TConfig>) {
patchState(store, {
isOpen: true,
loading: false,
config: options.config,
result: undefined,
error: undefined,
metadata: options.metadata,
preventClose: options.preventClose || false,
});
},
updateConfig(config: Partial<TConfig>) {
if (!store.isOpen()) return;
patchState(store, {
config: { ...store.config(), ...config } as TConfig,
});
},
close(result?: TResult, forceClose = false) {
if (!forceClose && (store.loading() || store.preventClose())) {
return;
}
patchState(store, {
isOpen: false,
loading: false,
result,
error: undefined,
preventClose: false,
});
},
closeWithError(error: unknown) {
patchState(store, {
isOpen: false,
loading: false,
error,
result: undefined,
});
},
reset() {
patchState(store, {
isOpen: initialState.isOpen,
loading: initialState.loading,
config: initialState.config,
result: initialState.result,
error: initialState.error,
metadata: initialState.metadata,
preventClose: initialState.preventClose,
});
},
}))
);
}Some functions and states might be a bit redundant but I think they are nice to have. This feature can now be used to handle dialog states for any dialog with any configuration you want.
What's Next?
Pagination! This is a common feature in many applications. Typically, a REST API will return a paginated response, and combined with HTTP operations, the store will become pretty powerful.
More links to explore
That's all for now—hopefully, you found this post helpful and maybe you can use this feature in your own Angular application :)
